Highlights:

• Premium Quality Arduino Uno R3 Board
• ATmega328P Microcontroller
• USB Programming Cable Included
• 14 Digital I/O & 6 Analog Inputs
• PWM, UART, SPI & I2C Support
• Ideal for Robotics, IoT & Automation Projects

Product Images are shown for illustrative purposes only and may differ from the actual product.

Product Description

The Arduino Uno R3 High-Quality Edition is one of the most popular and trusted microcontroller development boards for Robotics, IoT, Automation, Embedded Systems, and DIY Electronics Projects. Powered by the ATmega328P microcontroller, it delivers reliable performance and is suitable for both beginners and professional developers.
বোর্ডটিতে রয়েছে 14 Digital I/O Pins, 6 PWM Outputs এবং 6 Analog Input Pins, যা বিভিন্ন Sensors, Servo Motors, Motor Drivers, LCD Displays, WiFi Modules এবং অন্যান্য electronic components-এর সাথে সহজে কাজ করতে সক্ষম। এছাড়াও UART, SPI এবং I2C Communication Protocol support থাকায় বিভিন্ন device ও module সংযোগ করা আরও সহজ হয়।
Built with high-quality PCB and premium components, this edition ensures stable operation, durability, and long-term reliability. আপনি যদি Arduino Programming শিখতে চান, Robotics Project তৈরি করতে চান অথবা IoT ও Automation নিয়ে কাজ করতে চান, তাহলে এটি একটি চমৎকার choice।
USB Programming Cable Included, তাই box থেকে বের করেই Arduino IDE ব্যবহার করে programming শুরু করতে পারবেন।

Key Features

• High-Quality Arduino Uno R3 Compatible Design
• Original ATmega328P Microcontroller
• Premium PCB & Reliable Components
• USB Programming Cable Included
• 14 Digital I/O Pins
• 6 PWM Output Pins
• 6 Analog Input Channels
• Supports UART, SPI & I2C Communication
• Compatible with Arduino IDE
• Excellent for Learning, Prototyping & Product Development

---

Applications

• Robotics Projects
• IoT Development
• Home Automation Systems
• Sensor Interfacing
• Educational Learning Kits
• Embedded System Prototyping
• DIY Electronics Projects
• Smart Device Development
• Industrial Monitoring Systems

---

Technical Specifications

What is the pinout of the Arduino Uno?

Pin No.	Pin Name	Pin Type	Description
1	Reset	Reset	Resets the microcontroller when pulled LOW; usually connected to the reset button
2–3	TX, RX	Serial	Digital pins 0 (RX) and 1 (TX) for serial communication
4–9	D2 – D7	Digital I/O	General-purpose digital I/O pins
10–13	D8 – D13	Digital I/O	General-purpose digital I/O pins (D13 has built-in LED)
14–19	A0 – A5	Analog Input	Analog input pins can also be used as digital I/O pins
20	AREF	Reference	External voltage reference for analog inputs
21	3V3	Power	3.3V output from onboard regulator (max 50mA)
22–23	GND	Ground	Ground pins
24	VIN	Power	External power input
25	5V	Power	5V regulated output
26–28	SPI Pins	SPI	D10 (SS), D11 (MOSI), D12 (MISO), D13 (SCK)
29–30	A4 – A5	I2C	I2C pins (SDA, SCL)
31–36	PWM Pins	PWM	PWM capable pins: D3, D5, D6, D9, D10, D11

---

Package Includes :

1 x Arduino Uno R3
1 x USB Cable.
