Key Features:

• Non-contact distance measurement
• 2cm – 400cm detection range
• Up to 3mm measurement accuracy
• 40KHz ultrasonic transmitter and receiver
• Low power consumption
• Simple 4-pin interface
• Fast response time
• Easy integration with Arduino, ESP32, STM32 and Raspberry Pi
• Reliable obstacle detection capability

Product Images are shown for illustrative purposes only and may differ from the actual product.

Product Description:

HC-SR04 Ultrasonic Sonar Sensor একটি জনপ্রিয় distance measuring module যা ultrasonic sound wave ব্যবহার করে কোনো বস্তুর দূরত্ব নির্ণয় করে। Sensorটি 40KHz ultrasonic pulse transmit করে এবং object থেকে প্রতিফলিত echo signal গ্রহণ করে distance calculate করে।

এর 2cm থেকে 400cm measuring range এবং 3mm accuracy থাকার কারণে এটি Robotics, Obstacle Avoidance Robot, Smart Parking System, Water Level Monitoring, Home Automation এবং Arduino-based projects-এ ব্যাপকভাবে ব্যবহৃত হয়। Sensorটি non-contact measurement প্রযুক্তি ব্যবহার করে, ফলে কোনো বস্তুর সাথে শারীরিক সংযোগ ছাড়াই নির্ভুল distance measurement সম্ভব।

Applications:

• Obstacle Avoidance Robot
• Autonomous Vehicle Projects
• Distance Measurement Systems
• Water Tank Level Monitoring
• Smart Parking Systems
• Security and Detection Systems
• Arduino & IoT Projects
• STEM Education Projects
• Automation and Robotics

Technical Specifications:

Parameter				Specification
Operating Voltage				DC 5V
Working Current				15mA
Working Frequency				40KHz
Maximum Measuring Range				4m (400cm)
Minimum Measuring Range				2cm
Measuring Angle				15°
Trigger Input Signal				10µs TTL Pulse
Echo Output Signal				TTL Level Signal (Pulse Width Proportional to Distance)
Dimensions				45 × 20 × 15 mm

Please allow 5% measuring deviation due to manual measurement.

Note: Product specifications may vary slightly depending on manufacturing batch and supplier.

Package Includes:

• 1 × HC-SR04 Ultrasonic Distance Sensor Module

---
