Highlights:
- Infrared Flame Detection Sensor
- Adjustable Detection Sensitivity
- Analog & Digital Output
- LM393 Comparator Onboard
- Fast Fire Detection Response
- Operating Voltage: 3.3V–5V
- Compatible with Arduino, ESP32 & Raspberry Pi
Product Images are shown for illustrative purposes only and may differ from the actual product.
📦 Product Description
Flame Sensor Fire Detection Module হলো একটি infrared (IR) ভিত্তিক fire detection sensor, যা আগুনের শিখা থেকে নির্গত infrared light শনাক্ত করে দ্রুত সিগন্যাল প্রদান করে। Onboard LM393 comparator এবং adjustable sensitivity potentiometer থাকায় detection threshold সহজেই সেট করা যায়, ফলে বিভিন্ন project-এর জন্য এটি সহজে কনফিগার করা সম্ভব।
Moduleটি Analog (AO) এবং Digital (DO)—উভয় ধরনের output প্রদান করে। Digital output সরাসরি Arduino বা ESP32-এর GPIO-তে ব্যবহার করা যায়, আর Analog output ব্যবহার করে flame intensity পর্যবেক্ষণ করা সম্ভব। এটি Arduino, ESP32, Raspberry Pi, STM32 এবং অন্যান্য microcontroller-এর সাথে সহজেই interface করা যায়। Fire alarm system, smart home, robotics, industrial monitoring এবং DIY electronics project-এর জন্য এটি একটি জনপ্রিয় sensor module।
⭐ Key Features
- Infrared Flame Detection
- Detects Fire & Open Flame
- Analog (AO) & Digital (DO) Output
- LM393 Comparator IC
- Adjustable Sensitivity
- Fast Response Time
- Operating Voltage: 3.3V–5V DC
- Power & Status LED Indicators
- Easy 4-Pin Interface
- Compact PCB Design
🔧 Applications
- Fire Alarm Systems
- Flame Detection Projects
- Arduino & ESP32 Projects
- Smart Home Automation
- Robotics & Automation
- Industrial Safety Systems
- DIY Electronics
- STEM Education
📊 Technical Specifications
| Specification | Details |
|---|---|
| Model | Flame Sensor Module |
| Sensor Type | Infrared (IR) Flame Sensor |
| Comparator IC | LM393 |
| Operating Voltage | 3.3V–5V DC |
| Output Type | Analog (AO) & Digital (DO) |
| Detection Angle | Approx. 60° |
| Detection Wavelength | 760–1100nm |
| Sensitivity | Adjustable via Potentiometer |
| Interface | VCC, GND, AO, DO |
| Indicator LEDs | Power LED & Output LED |
| Operating Temperature | -25°C to +85°C |
| Dimensions | Approx. 32 × 14 mm |
📦 Package Includes
- 1 × Flame Sensor Fire Detection Module
⚠️ Important Notes
- This module detects flame and infrared radiation, not smoke or combustible gases.
- Detection distance depends on the flame size, surrounding light, and installation angle.
- Adjust the onboard potentiometer for the desired sensitivity before use.
- Product images are shown for illustrative purposes only and may differ from the actual product.
